The symptom that made no sense
The first time we saw it, we didn’t trust the dashboard. A distributed training job was scheduled and healthy — every pod was running, no crashes, no OOMKills, nothing in the logs. And yet more than half the GPUs we were paying for sat idle, and training never actually started. Every health check was green, and nothing was computing.
A metaphor that finally made it click
We kept reaching for a way to explain it, and this is the one that stuck. Imagine a sold-out concert hall. Every musician is in their seat, instruments tuned, the hall lit. But the conductor was shown to the wrong wing of the building — and the fire-safety doors, doing exactly their job, sealed that wing off. The result is a full, expensive hall and complete silence.
That is a GPU cluster in this failure mode. The conductor is the training coordinator. The musicians are the GPU workers, who can only play in sync, through the conductor — the same way distributed training synchronizes gradients through a coordinator. And the fire doors are the network policy: a correct, intentional safety rule that nobody told the scheduler about.
The root cause: two correct systems, collectively wrong
Kubernetes scheduling is topology-agnostic by design. It places pods based on available resources — CPU, memory, GPU count — without reasoning about which availability zone a pod lands in. Kubeflow inherits that assumption.
Cilium, on the other hand, is topology-aware. Operators use CiliumNetworkPolicy to draw zone boundaries for blast-radius isolation, compliance, cost control, or to protect an expensive dedicated GPU pool. That’s good security hygiene — and Cilium can’t reschedule a pod that has already been placed.
Put those two together and you get a class of problem where each system makes an individually correct decision, and together they’re wrong. The coordinator lands in one zone, the GPU workers in another, and the network silently blocks the connection between them. No one holds the single map that shows both the pod placement and the locked doors at once.
It’s a spectrum, not a single bug
What surprised us most is that the same root cause shows up three different ways in production:
- Hard block. A zone-boundary network policy denies the connection outright. Workers can’t reach the coordinator and training never starts. You notice in seconds.
- Cross-zone latency. With no hard block, just distance, gradient synchronization (NCCL AllReduce) pays cross-zone round-trip time on every step. Throughput quietly drops 30–60% with no error at all. You notice in hours, if you’re paying attention.
- Cross-AZ egress cost. The traffic crosses availability zones and shows up only on the cloud bill as inter-AZ data transfer. You notice in days, on the invoice.
The demo we built reproduces the first case because it fails cleanly and visibly. But the second and third are the ones that quietly drain budgets in real clusters.
The fix
The surprise is how little you have to change. We didn’t touch Cilium — the locked doors stay locked, because the security policy was never the problem. And we didn’t patch Kubernetes or Kubeflow. We simply gave the scheduler the one piece of information it was missing: keep the whole training group together, in a zone whose network path is open.
In practice that’s a few lines of Kubernetes-native YAML on the workload spec: nodeAffinity to pin the group to the GPU zone, topologySpreadConstraints to co-locate the coordinator and workers, and a toleration so the coordinator can actually land on the GPU-tainted nodes. Once every communicating pod shares a zone, the traffic is intra-zone — the hard block disappears, the latency disappears, and the cross-AZ egress disappears. One fix, all three symptoms.
If you don’t want to hard-code a zone name, podAffinity with a zone topology key achieves the same thing by relationship: place the workers in whatever zone the coordinator landed in. Same idea, portable across clusters.
In our lab, GPU utilization went from around 40% to around 85% the moment the group was co-located.
What we took away
Your Container Network Interface (CNI) has opinions about topology that your scheduler can’t see. Topology-aware network policies are silent to the Kubernetes scheduler — and that silence is where the failure lives.
The fix is Kubernetes-native. No CNI change, no framework patch — just topology spread constraints and affinity in the workload spec.
Instrument before you need it. GPU utilization and pod-zone metrics in Prometheus and Grafana exposed this for us in seconds; without them it can take days.
The pattern generalizes. Any topology-aware CNI plus any distributed ML framework can hit the same wall. It isn’t specific to Cilium or Kubeflow.
Try it yourself
We packaged the whole thing as a reproducible lab — a kind cluster with GPU and CPU zones, the Cilium policy, Prometheus recording rules, a Grafana dashboard, and before/after demo scripts:
Repo: https://github.com/ram2valar/kubeflow-cilium-lab
Talk recording (KubeCon + CloudNativeCon India 2026): https://www.youtube.com/watch?v=BG9XGouyM9c
Spin it up, watch the GPUs go idle, apply the fix, and watch them come back.
