In May, we released the Prusa ColorMix, our open-source color mixing model, based on the community project Full Spectrum. We promised you then that we’re working on a dedicated filament bundle.
So we spent the summer developing and testing, and here are the results: new translucent Prusament PLA with five colors for mixing, two spools for adding glitter, and three new PLA colors as a vivid alternative!
A little recap
The ColorMix comes as a feature in EasyPrint and PrusaSlicer. Using any multi-color printer, it allows you to create additional color tones from the loaded filaments. It works similarly to inkjet 2D printing. There, thanks to a method called Halftoning, all colors are printed from just Cyan, Magenta, Yellow, and Black (CMYK) ink in a varying pattern of dots.
In 3D printing, we alternate the colors by layers. For example, a 50% cyan, 50% yellow combination creates green when viewed from a normal viewing distance. The starting combination is CMYW, where W stands for white, providing enough options when printing on a 4T multi-material printer. We need white because we print in the air, instead of on paper.
Black can be mixed from an equal ratio of cyan, magenta, and yellow. But due to the nature of the method, it’s blueish grey, rather than truly black. The Prusa XL+ Five-head and the MMU3 unlock the option of adding black filament and mixing the CMYWK color palette, which results in 45 shades. The CORE family printers equipped with the Bondtech INDX upgrade add the possibility to have three extra colors.
What is out there
One of our favorite features of the ColorMix is that it isn’t actually dependent on the filaments. The software model is calibrated against actual prints. We store this data in the OpenPrintTag Material Database, so we can reliably predict the result of mixing any Prusament PLA colors.
The advantage of using the CMYWK colors lies in their convenient coverage of the color spectrum. Also, because the color model is similar to painting with water-based colors, it is quite easy for a layman to imagine the mixing outputs.
While bringing the ColorMix to the Prusaverse, we tested most of the CMYW and CMYWK filament sets available on the market. The majority of them are opaque and have saturated colors. The printed models then have nicely bright colors. However, on surfaces that are not completely vertical, we see a strong stripy pattern of the alternating layers.
There are very few translucent CMYW(K) options on the market, and they provide much smoother blending of the colors, especially of the cyan, magenta, and yellow tones. But we struggled to find a proper white and black for mixing.
To blend or not to blend
Based on this testing, we decided to develop our own ColorMix set, one that is semi-translucent and includes shades of black and white that are great for the mixing, as this is a gap in the market. We wanted to keep the colors bright and minimize the stripiness at the same time.
Translucent filaments blend well together, and when used in a 1:1 ratio of two colors, it is really hard to tell that this is a ColorMix print, even from a close look. We get a proper green, orange, and violet.
As a side effect, the translucency solves the problem of the horizontal surfaces pretty well. On the test model, we see that even the flat top and bottom layers look like the mixed color.
Getting a nice mix out of the CMY set is quite easy. The tricky part was finding the right opacity for the black and white filament. The ColorMix results are always towards the darker side when mixing two colors, so they are quickly overpowered by black. Opaque white makes the mixes pastel-like, rather than just lighter color shades. We played around with the pigments and found a set we named PLA ColorMix, including Cyan, Magenta, Yellow, Black and White filaments with just the right relative opacity for perfect mixing. Other brands usually have just a grey filament to complete the bundle, but that doesn’t work very well for any kind of shading.
Funnily, when we found the optimal translucent match, we started to miss the bright colors. That’s why we decided to keep the saturated cyan, magenta, and yellow filaments with which we started the testing, and we also added them to the PLA portfolio under the name PLA CMYK. You can choose between the brightness and the blending, depending on the outcome you need to achieve or your model’s geometry. The CMYK filament hides any infill structure that might be visible through the ColorMix ones. As the fourth filament, the CMYK set uses Prusament PLA Pristine White. The ColorMix White has a too light saturation for them.
As mentioned above, our ColorMix filaments are semi-translucent. This property allows light to pass through thin layers, causing colors to stack optically rather than block each other out. At the same time, they do block light when printed in larger volume. Their translucency is nicely visible when printing a model in vase mode.
A touch of glitter
With three more filament slots on the CORE One+ INDX, we wondered what else might be worth adding. Because of the popularity of our Galaxy PLAs, we decided to offer a bit of glitter for every color.
It comes in the form of ColorMix Gold Glitter and Silver Glitter. Both are based on PLA Natural, so they don’t influence the color tones. You can use them together with the ColorMix CMYWK colors. Besides the glitter, they add a lot of shades on the black & white scale.
But more than that, you can turn any PLA print into a “Galaxy” one. By simply using a 1:1 mix of any PLA with one of the glitters, you get a sparkling look. This works best with dark colors: Blood Red, Emerald Green, Royal Blue, or Anthracite Grey are good examples. The ColorMix glitter doesn’t decrease the intensity of these colors.
You can even mix the glitters with PLA Woodfill, which can be interesting for printing home decor. By using two different ratios of the filaments, you subtly increase the contrast between the surfaces.
Colors and pricing
Right now we are launching the translucent PLA ColorMix in the five basic colors: Cyan, Magenta, Yellow, White, and Black, and the accent pair of glitter, Gold and Silver. You can get 1 kg for 32.99 USD / 32.99 EUR (VAT incl.).
Because they make the most sense when used together, you can also get a PLA ColorMix bundle of all seven filaments for 209.99 USD / 180.49 EUR (VAT incl.).
In addition to that, we add the PLA CMYK filaments, the opaque version of Cyan, Magenta, and Yellow. The come together in a PLA CMYK bundle of four spools, including Prusament PLA Pristine White, which is a great combination for 4-toolhead printers. When adding black, we recommend the ColorMix Black. The price of 1 kg is the same and the bundle is available for 143.99 USD / 123.99 EUR (VAT incl.).
To help you imagine how many color combinations you get from the available filaments, we prepared an overview table:
Where ColorMix stands out
As a 3D printing technique, this is quite impressive, but there aren’t many prepared models yet. Let’s have a look at some possible applications.
It’s not only about adding more colors, the advantage is that you create shades of similar colors. Thanks to that, the ColorMix prints look less like cheap toys. Often you don’t need five or eight different colors for a model but you need to highlight its structure or distinguish its features.
We find it a great option for all sorts of educational models. They need to be colored to be descriptive, like the cells above.
But don’t forget that it works for any filament, whether you need to print flame imitation, engine parts for miniatures, or a nature scene, it will always look more natural when you use the method for shading. And ideally, such models should look similar to the real thing. Going beyond the new filament bundles, we can show this on the anatomic model of the heart, where a mix of PLA Blood Red and PLA Vanilla White was used to separate the atria and ventricles.
The ColorMix bundle allows you to use a large color palette without the need to own a large filament library. This is very convenient for printing toys, gifts, or decoration pieces.
Combining the black and white filaments with both glitters creates about 20 shades on the grayscale. This presents an opportunity to make sculptures and architecture models look more realistic or print stylish black and white photos.
Tips and tricks
There are a few rules to adhere to. Firstly, use a layer height of a maximum of 0.15 mm. This provides very good results, as you see in the pictures throughout this article. For a perfect outcome, 0.1mm layer height would be even better but it adds a lot of printing time and usually it’s not necessary.
The recommended infill type is gyroid with 5-10% density, depending on the model’s geometry. Because of the translucency, the infill might sometimes be visible, and this way the structure is uniform. Don’t forget that the best result is achieved on surfaces printed vertically.
One important remark: we’d like to set a convention for the order of the filaments to make it easy to share and print each other’s models. All the models designed for the ColorMix filament that we share have them loaded in the following order: Cyan, Magenta, Yellow, White, Black, Gold, and Silver. The order is the same whether the printer has four, five or eight tools. You can set this in PrusaSlicer and save it as a preset.
It doesn’t end here
With the software color model for the mixing, the implementation in EasyPrint and PrusaSlicer, and the filament bundles ColorMix and CMYK, we now have all the tools ready for your smooth colorful printing experience.
We keep wondering about more and other ways to use the technique. One possibility is automated mapping of colors to 3D printing models, like this ColorMix Image mapper by our colleague Kryštof Kohout or the Color Mix Lab by Printables user MichaelQ.
It’s worth mentioning that new apps are now appearing faster than before, and there are all sorts of methods of automated coloring. An interesting option is the Gradient Chef by Printables user BreitIdeasInc.
Mixing four colors together would be technically possible but the results simply don’t look good. It’s like putting the brush in all the watercolors, eventually all you get is a muddy brown. But how about mixing different materials? For PETG, PC blend, and TPU this works very well, we’re just not yet sure what it is good for.
We’d like to encourage you to design, paint, and share your ColorMix creations on Printables.com and use the tag “colormix” to make them easy to find. We’re looking forward to seeing your ideas.
Happy printing!
