Taiwan Semiconductor Manufacturing Company and ASML Holding N.V. announced a collaborative initiative to lead the semiconductor industry’s transition to a larger-format Extreme Ultraviolet (EUV) lithography photomask.
While High NA EUV will be adopted for production using the current, 6-inch masks, the transition to larger, 12-inch masks is expected to further increase fab productivity, lower chipmaking costs and remove stitching constraints, benefiting the entire semiconductor industry. It will enable advanced chip manufacturers to fully leverage the advantages of High NA EUV, making future generations of leading-edge chips more cost-effective.
“We expect the adoption of High NA EUV to increase progressively along the device scaling roadmap, first using current 6-inch masks and then further supported by 12-inch masks, which enable greater scanner productivity and allow the industry to meet the demand for smaller, faster and more energy-efficient chips.” said Christophe Fouquet, president & CEO, ASML. “We are pleased by the strong initial support of semiconductor manufacturers, mask suppliers and partners for this initiative.”
“We have always believed that when the industry works together to solve complex problems, we unlock possibilities that no single company could achieve alone,” said TSMC Chairman and CEO Dr. C.C. Wei. “By bringing together expertise from across the industry’s value chain, we hope to keep providing the benefits of cutting-edge technology through continuous innovation that lowers barriers and puts advanced solutions accessible at scale.”
TSMC intends to use ASML’s High NA technology in high-volume manufacturing for advanced nodes starting in 2030. As technology nodes advance, TSMC expects the number of layers requiring High NA EUV will rise, driven primarily by the increasingly complex transistor architectures required for AI applications.
On September 7, in advance of the annual SPIE BACUS Conference in Monterey, California, ASML and TSMC established an industry-wide collaborative initiative to drive the transition to 12-inch photomasks. This effort aims to establish a 12-inch mask pilot line by 2031, paving the way for 12-inch High-NA lithography systems to enter advanced node production by 2033.
Underscoring broad industry support, major ecosystem partners and suppliers attended the event and expressed their interest in this transition.
Facts Only
* Taiwan Semiconductor Manufacturing Company and ASML Holding N.V. announced a collaborative initiative regarding Extreme Ultraviolet (EUV) lithography photomasks.
* High NA EUV will be adopted for production using current 6-inch masks.
* The transition to larger, 12-inch masks is expected to increase fab productivity and lower chipmaking costs.
* This transition aims to remove stitching constraints benefiting the semiconductor industry.
* ASML expects High NA EUV adoption to progress first with 6-inch masks, then supported by 12-inch masks.
* The goal of larger masks is to enable greater scanner productivity and meet demand for smaller, faster, and more energy-efficient chips.
* TSMC intends to use ASML’s High NA technology in high-volume manufacturing for advanced nodes starting in 2030.
* TSMC expects the number of layers requiring High NA EUV will rise due to complex transistor architectures for AI applications.
* ASML and TSMC established an industry-wide collaborative initiative on September 7th concerning 12-inch photomasks.
* The initiative aims to establish a 12-inch mask pilot line by 2031.
* The effort seeks to enable 12-inch High-NA lithography systems in advanced node production by 2033.
* Major ecosystem partners and suppliers attended the event and expressed interest in the transition.
Executive Summary
Taiwan Semiconductor Manufacturing Company and ASML Holding N.V. have initiated a collaboration to advance the semiconductor industry toward larger-format Extreme Ultraviolet (EUV) lithography photomasks. While High NA EUV will be used with current 6-inch masks for production, the transition to 12-inch masks is anticipated to increase fab productivity, reduce chipmaking costs, and eliminate stitching constraints across the industry. This transition aims to allow advanced chip manufacturers to fully utilize the benefits of High NA EUV for more cost-effective future chips.
ASML expects the adoption of High NA EUV to follow a roadmap: initially using 6-inch masks, followed by support from 12-inch masks to enhance scanner productivity and meet demand for smaller, faster, and more energy-efficient chips. TSMC plans to use ASML’s High NA technology for high-volume manufacturing on advanced nodes starting in 2030, anticipating an increase in the number of layers requiring this technology due to complex AI-driven transistor architectures. To facilitate this, ASML and TSMC established a collaborative initiative on September 7th to drive the transition to 12-inch photomasks, aiming for a 12-inch mask pilot line by 2031 and enabling 12-inch High-NA lithography systems in advanced node production by 2033. The effort has garnered support from major ecosystem partners and suppliers.
