A new unified API for extending Envoy proxies in Istio with WebAssembly and Lua, supporting both sidecar and ambient mode.
Mesh extensibility has always been a core tenet of Istio’s design. By allowing users to inject custom logic directly into the data plane, Istio enables a wide range of use cases for performing custom authentication, collecting specialized telemetry, or transforming requests and responses on-the-fly.
Until now Istio’s only supported extensibility API was WasmPlugin
, which served WebAssembly-based extensions. Users who wanted to leverage Lua scripts could only do so indirectly via EnvoyFilter
, a low-level mechanism that is powerful but easy to misconfigure.
Istio 1.30 introduces the TrafficExtension
API — a single, unified API for configuring Wasm and Lua extensions for Envoy-based sidecars, gateways and waypoints.
What is TrafficExtension?
TrafficExtension
is a new Istio API that replaces WasmPlugin
as the primary proxy extensibility mechanism. It supports two extension types:
- Lua scripts — inline Lua scripts embedded directly in the resource, executed within Envoy with no module distribution required. Best for simple header manipulation, logging, and conditional logic. Applied to Layer 7 (HTTP) traffic only.
- WebAssembly plugins — Proxy-Wasm sandbox modules loaded dynamically from OCI image registries. Supports multiple languages (Go, Rust, C++, AssemblyScript) and is recommended for complex processing, policy enforcement, telemetry collection, and payload mutations. Applied to Layer 7 (HTTP) or layer 4 (TCP) traffic.
See the TrafficExtension concepts page for detailed guidance on choosing between Lua and Wasm for your use case.
Writing extensions
Lua
Lua scripts are written inline. The following example reads an x-number
request header, computes whether the value is even or odd, and adds an x-parity
response header:
apiVersion: extensions.istio.io/v1alpha1
kind: TrafficExtension
metadata:
name: parity
namespace: istio-system
spec:
selector:
matchLabels:
istio: ingressgateway
lua:
inlineCode: |
function envoy_on_request(request_handle)
local number = tonumber(request_handle:headers():get("x-number"))
if number == nil then return end
local parity = number % 2 == 0 and "even" or "odd"
request_handle:streamInfo():dynamicMetadata():set(
"envoy.filters.http.lua", "parity", parity)
end
function envoy_on_response(response_handle)
local meta = response_handle:streamInfo():dynamicMetadata():get(
"envoy.filters.http.lua")
if meta == nil then return end
response_handle:headers():add("x-parity", meta["parity"])
end
WebAssembly
Wasm modules are loaded from OCI registries. The following example applies basic authentication to the /productpage
path using a prebuilt Wasm plugin:
apiVersion: extensions.istio.io/v1alpha1
kind: TrafficExtension
metadata:
name: basic-auth
namespace: istio-system
spec:
selector:
matchLabels:
istio: ingressgateway
phase: AUTHN
wasm:
url: oci://ghcr.io/istio-ecosystem/wasm-extensions/basic_auth:1.12.0
pluginConfig:
basic_auth_rules:
- prefix: "/productpage"
request_methods: ["GET", "POST"]
credentials: ["ok:test"]
Prebuilt Wasm extensions are available in the Istio ecosystem repository. To build your own, see the Proxy-Wasm SDKs.
Targeting
TrafficExtension
supports two targeting mechanisms suited to different deployment modes.
selector
targets sidecar proxies using label selectors. A resource created in istio-system
applies cluster-wide; a resource in any other namespace applies only to workloads in that namespace.
targetRefs
targets Gateways or Services directly — required for ambient mode waypoint proxies, which do not map to workloads using label-based selectors. The same basic-auth
extension applied to an ambient Gateway looks like this:
apiVersion: extensions.istio.io/v1alpha1
kind: TrafficExtension
metadata:
name: basic-auth-gateway
spec:
targetRefs:
- kind: Gateway
group: gateway.networking.k8s.io
name: bookinfo-gateway
phase: AUTHN
wasm:
url: oci://ghcr.io/istio-ecosystem/wasm-extensions/basic_auth:1.12.0
pluginConfig:
basic_auth_rules:
- prefix: "/productpage"
request_methods: ["GET", "POST"]
credentials: ["ok:test"]
Ordering extensions
When multiple extensions target the same proxy, phase
and priority
control execution order.
phase
places the extension at a known point in the filter chain:
| Phase | Position |
|---|---|
AUTHN | Authentication phase |
AUTHZ | Authorization phase |
STATS | Statistics/observability phase |
| (unset) | Near the router (default) |
Within a phase, priority
breaks ties — higher values run earlier in the request path.
Migrating from WasmPlugin
TrafficExtension
supersedes WasmPlugin
as the recommended extensibility API. Existing WasmPlugin
resources are fully compatible with the new API — in fact, Istio now internally transforms all WasmPlugin
resources into TrafficExtension
resources before generating configuration to distribute to Envoy.
There is no forced migration in Istio 1.30. When you are ready to migrate, the TrafficExtension API reference documents the full spec.
Get started
- TrafficExtension concepts — extension types, targeting, and ordering explained
- Execute WebAssembly modules — step-by-step task for sidecar deployments
- Execute Lua scripts — step-by-step task for sidecar deployments
- Extend waypoints with WebAssembly — ambient mode guide
- Extend waypoints with Lua — ambient mode guide
Community
TrafficExtension
is alpha, and your feedback directly shapes the API before it stabilizes. If you encounter issues or have suggestions, please open a GitHub issue or join the discussion on Istio Slack. We’d love to hear how you’re using proxy extensions in your deployments.
Ready to get involved? Visit Istio’s community page.
